| LATHE SPECS | INCHES |
METRIC
|
||||
| WORK AREA HEIGHTS | 12.5" |
320 MM
|
||||
| SPINDLE CENTER TO COLUMN | 7.10" |
180 MM
|
||||
| MAXIMUM DRILL CAPACITY | .400" |
10 MM
|
||||
| MAXIMUM MILL CAPACITY | .875" |
22 MM
|
||||
| COLUMN DIAMETER | 2.60" |
60 MM
|
||||
| SPINDLE DIAMETER | 2.40" |
50 MM
|
||||
| SPINDLE TRAVEL | 2.00" |
50 MM
|
||||
| MILL TABLE SIZE | 17.75"x6.30" |
50 MMx160 MM
|
||||
| LONGITUDINAL TRAVEL | 11.50" |
290 MM
|
||||
| CROSS TRAVEL | 5.50" |
140 MM
|
||||
| SPINDLE TAPER | MT2 | |||||
| SPINDLE ACCURACY | .0002" |
005 MM
|
||||
| SPINDLE SPEEDS (4) |
440-670-1340-2160
RPM
|
|||||
| MILL HEAD SWIVELS | 360° | |||||
| MOTOR CAPACITY | 1/3 HP |
250 W
|
||||
| ELECTRICS | 110V | |||||
| SPACE REQUIREMENTS | 23"x22"x32" | |||||
| (LxWxH) |
585 MMx559MMx813MM
|
|||||
| NET WEIGHT | 200 LBS |
91 KGS
|
||||
 |
||||||
